Popular Science: Industrial Hose Pump — The "All-Round Devourer" in Complex Conditions
In the grand landscape of modern industry, traditional conveying equipment often falls short when faced with complex fluids that are highly viscous, strongly corrosive, or heavily loaded with solid particles. Under these harsh conditions, the Industrial Hose Pump acts as an "all-round devourer" that ignores environmental debuffs, shining brilliantly in industries such as metallurgy, rare earth, desulfurization, water treatment, papermaking, paint, titanium dioxide, and compound fertilizers. Capable of serving as a pool-cleaning self-priming pump, filter press pump, and mud pump, it comes in single-tube and double-tube forms, always ready to tackle high-difficulty challenges.

Hardcore Configurations of Industrial Hose Pumps
The powerful performance of an excellent industrial hose pump relies on reasonable hardware configurations:

Standard Configuration: It is usually equipped with a standard Y-series motor and a cycloidal pinwheel reducer, featuring horizontal inlets and outlets. Its simple operation logic and rock-solid quality provide the market with highly stable and reliable output.
Special Configuration: For more extreme demands, it can be equipped with variable frequency motors, high-protection motors, explosion-proof motors, or hard-tooth surface reducers as needed, with adjustable inlet and outlet directions. There is even a Mobile Industrial Hose Pump, acting like a "mobile fortress." It has threaded holes on the side of the base, equipped with four wheels and a steering wheel with brakes at the front, allowing it to move freely and stand firm even in harsh field environments.
The "Maintenance and Cultivation" Manual for Industrial Hose Pumps
To keep this equipment in peak condition for a long time, the following 10 operational rules must be strictly remembered:

Stable Base: The pump must be placed steadily to reduce vibration and minimize noise.
Reserve Space: A flexible or rigid short section (about 80 to 100 cm) should be reserved between the outlet flange and the pipeline connection to leave room for future hose replacement.
Fearless Self-Priming: There is no need to prime the pump before starting. It can be installed above the material level without auxiliary pipelines, provided the height difference does not exceed 5 meters.
Adapt to Local Conditions: If the conveyed medium has extremely high viscosity, many particles, easy sedimentation, and poor fluidity, the pump should be installed below the material.
Smooth Pipelines: Minimize bending during piping, especially right-angle elbows. Generally, the outlet pipe diameter should match the hose diameter. For long pipelines or highly viscous materials, the outlet pipe diameter should be 1.2 to 1.3 times the hose diameter.
Forbidden Valves: Check valves are absolutely not allowed at the inlet and outlet.
Pressure Perception: A pressure gauge must be installed at the outlet to continuously monitor the equipment's operating status.
Bidirectional Flow: The inlet and outlet are in the same direction and can be interchanged at any time, providing great layout flexibility.

Cooling and Quenching: Coolant must be added to the pump casing (taking up 1/3 of the viewing window). Its function is to remove frictional heat, protect bearings, and allow the hose to operate at an appropriate temperature for a longer life, achieving a perfect seal with no leakage or pollution.
Rebirth (Hose Replacement and Adjustment):
a. When replacing, first loosen and remove the pipe clamps at both ends, then unscrew the lifting ring bolt at one end to pull out the short pipe. Jog the motor to push the old hose out, insert the new hose from the end where the short pipe was removed into the gap between the roller and the casing, jog the motor again to swallow the hose, and finally secure the lifting ring and clamps. (Note: When installing, ensure the hose fits tightly against the pump casing before operating.)
b. After the hose has been running for about 200 hours, it can be rotated 90°. For a single-hose pump, the hose can also be pulled back and forth to change the pressure point, significantly extending its physical lifespan.
English Concluding Remark
The industrial hose pump stands as a testament to engineering ingenuity, seamlessly handling the most demanding and abrasive materials across various sectors. By strictly following proper configuration and maintenance protocols, industrial operators can unlock the full potential of these robust machines, ensuring uninterrupted workflow and remarkable cost-efficiency.
