Recently, many customers have reported that single-layer screening equipment simply cannot meet the precise grading requirements for construction aggregates. They need fine sand, medium sand, and coarse sand all separated in a single pass. Today, we would like to introduce a highly versatile piece of equipment — the Multi-Layer Vibrating Sand Washing and Screening Machine. This machine supports up to three layers of screening mesh, allowing a single feed of raw material to be simultaneously sorted into four different specifications. This dramatically improves production efficiency while ensuring thorough screening with minimal material loss.

Exterior View of Multi-Layer Vibrating Screening Machine

Detailed Component View

In terms of pricing, the multi-layer vibrating screening machine is priced higher than conventional single-layer equipment. This is entirely determined by the quality of its materials and manufacturing processes. Precision screening through high-frequency vibration places extremely high demands on the steel grades, welding craftsmanship, and overall structural integrity of the machine — ensuring quality you can rely on.

Hopper: The machine's hopper is welded from 4.5mm thick high-quality steel plate, with a maximum feed particle size of 25cm. The standard hopper dimensions are 3.8×1.6 meters. Customization for larger hoppers is also available to match different production capacities.

Customizable Hopper Size

Motor: The conveying motor uses an 11kw full-copper winding motor. The vibration eccentric motor is available in 5.5kw or 7.5kw full-copper winding options depending on the number of screening layers. The copper-core coil delivers higher conductivity, more durable performance, and significantly reduces the risk of motor burnout.

Durable Full-Copper Motor

Screening Mesh and Deck: The screening mesh is precision-woven from high-manganese steel thick wire, offering outstanding wear resistance. The screen deck is made from 8mm reinforced steel plate, maintaining structural stability under prolonged high-frequency vibration and significantly extending the service life of the machine.

Reinforced Screen Deck Display

Components: The roller bearings are selected to national standard specifications. The bearing housing is cast from integrated steel for strength and reliability. The counterweight iron blocks are made from 16mm thick double-layer steel plates. Four sets of vibration-dampening spring groups, with three springs per set, effectively absorb vibration impact, reduce mechanical wear during operation, and extend the overall service life. Additionally, the machine supports the installation of a mobile wheel system with four-wheel independent support, enabling smooth and stable relocation across various job sites.

Regarding equipment pricing, the final quotation varies depending on factors such as model configuration, number of screening layers, hopper size, and whether the mobile wheel system is included. Fluctuations in steel market prices and customized processing requirements may also affect the final price. If you would like a detailed equipment selection plan and the latest quotation, please feel free to contact Xiao Gen directly for a one-on-one customized consultation!
